TECHNICAL SPECIFICATIONS

Technical Management

kyle@soundfangled.com

Soundfangled Ltd. +44 (0) 7808 538 488

Digital Console

  • Allen & Heath - DLive C1500

  • Allen & Heath - CDM32 - I/o 32/16

    Network

  • Dante 64X64

  • Netgear Nighthawk.

  • Apple iPad 10'2 Retina 9th Gen

    Playback

  • AudioEngine B1 :: Pioneer 900 Nexus

  • Technics 1210 MK7 :: Isonoe isolators

Recording Capabilities

  • Straight to stereo - £20

  • Multitrack @ 96kbps (lossless) 32 channels - £50

  • Mixing in-house through SoundFangled at request.

    Speakers

  • 2 X TW AUDiO T20 Loudspeaker

  • 2 X TW AUDiO B18 Subwoofer, Cardiod DSC

  • 4 X TW AUDiO C15 Stage monitor

    Microphones

  • 1 X Shure B91

  • 3 X Audio Technica 4041

  • 4 X Sennheiser 604

  • 8 X Shure SM58

  • 4 X Shure SM57

  • 8 X Orchid DI

Amps

  • Dynacord IPX10:4

  • Dynacord IPX5:4

  • Connected via Analogue & Dante Network

    Hardware

  • 6 X K&M short boom mic stand

  • 10 X K&M tall boom mic stand

  • 3 X K&M equipment stands

    Power

  • 63A 1 ∅ Distro 32A(x2) - Powercon - 13A

    Signal Cables

  • Neutrix connector and Van Damm cable

  • 6 X 3m TS

  • 4 X 10m XLR M>F

  • 10 X 1.5m XLR M>F

  • 10 X 6m XLR M>F

  • 16 X 3m XLR M>F

Stage Dimensions

  • 5.5m Width X 2m depth

  • + recess USC into archway:

  • 2.5m width X 0.8m depth

    Patch Bays

  • 3 X Vean Stage Box - 12/4 - positions DSC, USL, USR

  • Patch - 2X 16/4 10mtrs, position SR/SL

    Audio Spread

  • Average SPL [db] 101.0

Lights

Rear:

  • 2X Intimidator moving spots

  • 2X Vector 2.0 moving spots

  • 10X 100/32 LED PR100 Batons

    Front truss:

  • 2 X Eurolite TMH-H90 moving head spot

  • Eurolite 120 parcan

  • 2 X Shard moving wash

Hazer is included for all shows

Lighting policy: We have a strict warm white lighting policy, with movement and dynamics built in for shows.

Backline

Drums:

  • KD Custom shells - natural Finnish birch (20/16/12)

  • Ludwig Black Magic Snare

  • DW 5000 Hardware

  • Iron Speed Cobra pedal & HiHat

@ £80 whole kit rental per session.

Cymbals:

  • Zildjian A-Custom 16” crash

  • Istanbul Hats, 16” crash

  • Zildjian 18” A-Custom ride

@ £20 whole cymbal set rental per session.

Amps:

  • Ampeg Micro VR solid state

  • Bugera Tube V22 head

  • Fender Hotrod Deluxe cab

  • Supro Delta King 10

@ £30 each rental per session.
